ENGINE GENERAL
8. FUEL SYSTEM LAYOUT
Injector Fuel Filter & Priming Pump
Fuel filter
Connector
Priming
pump
HP Pump
Fuel return port
Venturi
Low pres - sure fuel supply port
Fuel return port
Fuel tempera -
ture sensor
IMV connector
IMV valve
High pres -
sure fuel supply port
1.
2.
3.
4.
5.
HP Pump
