SSANGYONG Q151 User Manual

01-12
T/C oil supply pipe M16 1 25±2.5Nm
(Fitting Screw)
-
M10 1 17±2.0Nm
(Hollow Bolt)
-
T/C oil return pipe M6×16(to block) 2 10±1Nm -
M6×16
(to turbocharger)
2 10±1Nm -
EGR valve M8×30 3 25±2.5Nm -
Name Size
Numbers of
fastener
Tightening
torque (Nm)
Note (total
tightening
torque)
Hot water inlet pipe M6×12 2 10±1Nm -
Alternator M10×90 1 (LO) 25±2.5Nm -
M10×116 1 (HI) 46±4.6Nm -
Air conditioner
compressor
M8×85 4 25Nm -
Air conditioner bracket M6×25 4 10±1Nm -
Intake manifold M8×35 2 25±2.5Nm -
M8×110 6 25±2.5Nm -
Oil filter module M8×40 6 25±2.5Nm -
M8×80 1 25±2.5Nm -
M8×140 2 25±2.5Nm -
Knock sensor M8×28 2 20±5Nm -
Camshaft position
sensor
M8×14 1 10~14Nm -
T-MAP pressure
sensor
M6×20 1 10±1Nm -
Exhaust manifold M8 10 40±4Nm -
Turbocharger M8 3 25±2.5Nm -
T/C support bolt M8 x 35 1 25±2.5Nm
(Turbo Side)
-
M8 x 16 1 25±2.5Nm
(Block Side)
-
