SSANGYONG Q151 User Manual

01-13
0000-00
Name Size
Numbers of
fastener
Tightening
torque (Nm)
Note (total
tightening
torque)
Idler pulley/tensioner
pulley
1 45±4.5Nm -
Glow plug M5 4 20±2Nm -
Vacuum pump M6×25 3 10±1Nm -
Timing gear case cover M6×40 7 10±1Nm -
M6×45 1 10±1Nm -
M6×50 3 10±1Nm -
Cylinder head cover M6×35 21 10±1Nm -
Oil dipstick gauge cover M6×16 1 10±1Nm -
Oil filter cap 1 25±2.5Nm -
Fuel rail M8×25 2 25±2.5Nm -
Injector clamp bolt M6×44 2 9±1.0Nm
130˚±10˚
-
High pressure pipe
(between high pressure
pump and fuel rail
assembly)
M17 1 30±3Nm -
High pressure pipe
(between fuel rail assembly
and injector)
M17 4 30±3Nm -
Crankshaft position
sensor
M5×14 1 8±0.4Nm -
Main wiring M6×16 5 10±1Nm -
Intake duct M8×25 4 25±2.5Nm -
Power steering pump M8×100 3 25±2.5Nm -
Cylinder head front
cover
M6×10 5 10±1Nm -
Ladder frame M8×35 5
30±3Nm -
EGR pipe bolt
(to air duct)
M6×16 2 10±1Nm -
EGR pipe bolt
(to EGR cooler)
M8×25 2 25±2.5Nm -
