6. TIGHTENING TORQUE
Name Size
Numbers of
fastener
Tightening
torque (Nm)
Note (total
tightening
torque)
Main bearing cap M12×82 10 55±5Nm,
180˚
Not-reusable
Connecting rod cap M9×52 8 40±5Nm,
90˚+10˚
50 ~80Nm
Crankshaft rear seal M6×20 6 10±1Nm -
Oil pump M8×35 3 25±2.5Nm -
Drive plate M10×22 8 45±5Nm,
90˚+10˚
Not-reusable
Isolation damper center
bolt
M18×50 1 200±20Nm,
180˚+20˚
660 ~ 720Nm
Not-reusable
Oil pan M6×20 18 10±1Nm -
M6×35 2 10±1Nm -
M6×85 2 10±1Nm -
M6×120 2 10±1Nm -
M8×40 2 25±2.5Nm -
Mounting nut for high
pressure pump
M14×1.5-8-1 1 65±5Nm -
Mounting bolt for high
pressure pump
M8×30 3 25±2.5Nm -
Cylinder head M13×150 12 85Nm
270°±10°
-
Camshaft cap M6×30 16 10±1Nm -
M8×60 4 25±2.5Nm -
Exhaust stud bolt 10 15±1.5Nm -
Exhaust sprocket M8x16.5 1 25±2.5Nm -
Chain tensioner screw
plug
M8x1.5 1 25±2.5Nm -
Coolant temperature
sensor
1 20±2.0Nm -
Belt auto tensioner M8×30(LOW) 1 25±2.5Nm -
M10×75(U
pp
er) 1 55±5.5Nm -
Water pump M6×25 7 10±1.0Nm -
