01-14
7. CODING AND INITIALIZATION
1) Engine Variant Coding
Unit Selection Description Remarks
Additional heater YES For PTC auxiary heater equipped
vehicle, select "YES"
YES
NO -
Gear box 5 MT "DSI 6 AT" is selected
automatically.
-
6 MT Select
5 AT(DC 5 AT) -
6 AT(DSI 6 AT) Select
7 AT(DC 7 AT) -
Immobilizer NO Select "YES" if the vehicle has
immobilizer.
-
YES YES
Fan PWM control Select "PWM" PWM fan
Relay -
Engine level control NO
YES
SKM key NO NO
YES -
Glow plug AQGS (CAN) Select "AQGS" AQGS (CAN)
Relay (K-line) -
A/C Refrigerant pressure
sensor
Select the appropriate system. Pressure sensor
for A/C refrigerant
NO -
Vehicle speed sensor CAN Select "CAN" if the vehicle has
ABS or ESP
CAN
WIRE -
Cruise control YES Select "YES" if the vehicle has
cruise control.
YES
NO -
G-sensor YES 2WD ABS & Non-ABS: NO
4WD ABS & ESP: YES
Select
NO Select
To Next Page
