02-3
0000-00
Cylinder block Piston protrusion 0.475 to 0.745mm -
Piston ring TOP ring end gap 0.20 to 0.40 mm -
2nd ring end gap 0.35 to 0.50 mm -
3rd ring end gap 0.2 to 0.40 mm -
Offset 0.3mm -
Head gasket Piston protrusion 0.475 to 0.540 1.2t -
0.541 to 0.649 1.3t -
0.650 to 0.745 1.4t -
Valve Clearance between
valve and piston
Intake 1.12 mm -
Exhaust 1.09 mm -
Valve recess Intake 0.6 to 1.0 mm -
Exhaust 0.6 to 1.0 mm -
1. ENGINE ASSEMBLY
Unit Description Specification Remark
Cylinder head Height 131.9 to 132.1 mm -
Flatness below 0.1 mm -
Valve protrusion Intake valve 0.6 to 1.0 mm -
Exhaust valve 0.6 to 1.0 mm -
Flatness on manifold
side
Intake manifold 0.08 mm -
Exhaust manifold 0.08 mm -
Connecting rod End play 0.5 to 0.31 mm -
Camshaft
A
xial end pla
y
Intake 0.1 to 0.35 mm -
Exhaust 0.1 to 0.35 mm -
Camshaft position
sensor
Distance between Camshaft position
sensor and sprocket
0.20 to 1.80 mm -
