08-17
4850-03
1) Front Brake
The front brake system uses the ventilated disc and double piston caliper.
Caliper carrier
Pad spring
Brake pad
Bolt-caliper
Brake disc
Caliper
Piston
Brake hose
Caliper assembly Brake disc Brake pad
