5
any of the programs chasing in Mix mode.
11. UP/CHASE REV. Button –
UP is used to modify a scene in Edit mode. CHASE REV. is to reverse the chasing direction of a
scene under Speed Slider control.
12. PAGE Button –
Tap to select pages of scenes from Page 1-4.
13. DEL./REV. ONE Button –
Delete any step of a scene or reverse the chasing direction of any program.
14. 3 Digit Display –
Shows the current activity or programming state.
15. INSERT / % or 0-255 Button–
INSERT is to add one step or steps into a scene. % or 0-255 is used to change display value cycle
between % and 0-255.
16. EDIT/ALL REV. Button –
EDIT is used to activate Edit mode. ALL REV. is to reverse the chasing direction of all programs.
17. ADD or KILL/REC. EXIT Button–
In Add mode, multiple scenes or Flash buttons will be on at a time. In Kill mode, pressing any
Flash button will kill any other scenes or programs. REC. EXIT is used to exit from Program or Edit
mode.
18. RECORD/SHIFT Button–
RECORD is used to activate Record mode or program a step. SHIFT functions only used with
other buttons.
19. MAS. A Button –
Brings channel 1-12 to full of current setting.
20. PARK Button –
Used to select Single/Mix Chase, bring Channel 13-24 to full of current setting, or momentarily
program a scene into Master B slider, depending on the current mode.
21. HOLD Button –
This button is used to maintain current scene.
22. STEP Button –
This button is used to go to next step when the Speed Slider is pushed to the bottom or in Edit
mode.
23. AUDIO Button –
Activates audio sync of chase and audio intensity effects.
24. Master A Slider –
This slider controls overall output of all channels.
25. Master B Slider–
This slider controls the chase of all channels.
26. BLIND Button –
This function takes the channel out of the chase of a program in
