A. Remove the screw located at the bottom of the speaker
enclosure.
A
B. Removing the two screws securing the bracket to the
vehicle. Then remove the two screws securing the bracket to the
enclosure.
Note: These 4 factory screws will be re-used for the SSV pods.
*This image is of passenger side .
B
A. Secure the drivers side bracket to the driver side pod using
the factory two screws.
A
B
C
D
B. Hold the pod up near its mounting location and connect the
factory harness.
C. Snap the speaker pod harness cover onto the pod making sure
the harness exits the cover through one of the two reliefs.
D. Use the provided Philips screw to secure the cover in place.
BR-2B65U
2023 SSV Works, Oxnard, Ca 93030 BR-2BR65 Rev. A. 4-24-23
