# PART NUMBER DESCRIPTION
1 80P20003-R CONVECTION FAN
2 80P20038-R PROOF OF FIRE SWITCH
3 80P20001-R COMBUSTION FAN
4 80P52628-R VACUUM SWITCH
5 80P52629-R MANUAL RESET HIGH LIMIT
6 80P52632-R CONTROL BOARD
7 80P30045-R T-STAT WIRE TERMINAL
8 80P52630-R WIRING TERMINAL BLOCK
9 80P20278-R AUGER MOTOR
10 80P20245-R AUGER GASKET
11 80P52232-R QUICK DISCONNECT GASKET
12 80P20168-R COMBUSTION FAN GASKET
13 80P53650-R EXHAUST ADAPTER WELDMENT
14 80P52887-R PIPE CONNECTOR ASSEMBLY
15 80P52957-R AUGER MOUNT BRACKET ASSEMBLY
16 80P30191-R AUGER MOTOR RETAINER BRACKET
17 80P20248-R 5/8” COLLAR WITH SETSCREW
18 80P52658-R CONTROL BOARD COVER
19 80P53785-R CONTROL BOARD MOUNT BOX
20 80P53681-R SLIDE TOP STANDOFF PLATE
21 80P20183-R PLASTIC HOPPER HANDLE
22 80P52944-R HEAT EXCHANGE BAFFLE
23 80P52375-R GLASS FOR DOOR
24 80P20022-R GLASS GASKET KIT
25 80P52357-R GLASS RETAINER
26 80P20132-R DOOR GASKET KIT
27 80P52947-R DOOR FRAME WELDMENT
28 80P53773-R DOOR HANDLE
29 80P53677-R HANDLE MOUNT PLATE ASSEMBLY
30 80P20131-R GOLD HANDLE COIL
30 80P20131-BN NICKEL HANDLE COIL
31 80P52237-R ASH CLEANOUT COVER
32 80P53631-R ASH LIP
33 80P52946-R ASH PAN
34 80P52568-R CORN RAKE ROD
35 80P52592-R SLIDE OUT BOTTOM ROD
36 80P53619-R COAL RAKE
37 80P53-R SLIDE OUT BOTTOM
38 80P53618-R CORN POT
39 80P30048 DECORATIVE GRILL – RIGHT SIDE
40 80P30047 DECORATIVE GRILL – LEFT SIDE
41 80P52316-LWC BRICK SIDE PANEL – RIGHT HAND
42 80P52302-LWC BRICK - BACK PANEL
43 80P52317-LWC BRICK SIDE PANEL – LEFT HAND
PARTS NOT SHOWN
80P20004-R POWER CORD
80P52693-R WIRING HARNESS
80P52956-R AUGERSHAFT WELDMENT
80P20057-R 5 AMP FUSE
26
Lancaster Operations & Maintenance Manual
