ST ST7735R - Page 114

ST7735R
V0.2 114 2009-08-05
Memory
Display
Top-left (0, 0)
ML="0"
Memory
Display
Top-left (0, 0)
ML="1"
Send first
Send 2nd
Send 3rd
Send last
Send first
Send 2nd
Send 3rd
Send last
Top-left (0, 0)
Top-left (0, 0)
Default
Status Default Value
Power On Sequence MY=0,MX=0,MV=0,ML=0,RGB=0,MH=0
S/W Reset No Change
H/W Reset MY=0,MX=0,MV=0,ML=0,RGB=0,MH=0
Flow Chart
Command
Parameter
Display
Action
Mode
Legend
Sequential
transter
MADCTL
1st parameter
B[7:0]
