ST STM32L4 - Page 81

GPIO Selection
• This example will use LED2 on the DK IoT board.
81
PB14
1
2
1. Use the find toolbar and type PB14
2. Select PB14 and set it to GPIO_Output mode.
Note: Board schematics can be found in the IoT board User
Manual (UM2153)
