4
GENERAL INFORMATION
C
lean a new pool as well as possible before filling pool and operating filter.
Excess dirt and large particles of foreign matter in the system can cause seri-
ous damage to the filter and pump.
K
eep pool water pH at recommended level (7.2 to 7.6).
Be sure both clamps are in place and knobs are securely tightened before
starting filter. If filter is improperly disassembled or assembled, it will explode
under pressure! To avoid danger of severe injury or major property damage,
always follow service instructions in this manual when working on filter!
NEVER operate this filter system at more than 50 pounds per
square inch (50 PSI/345kPa) pressure!
On a new pool installation, we recommend:
1. Disassemble the filter after the initial cleanup.
To prevent severe injury or major property damage, follow
instructions in your filter owner’s manual.
2. Remove and hose down the element assembly to remove contaminants.
Hazardous pressure.
Can cause severe
injury or major
property damage
from tank blow up.
Release all pressure
and read instructions
before working on
separation tank.
12" DIA.
(305)
4 7/8"
(124)
29 7/8"
(759)
40 5/8"
(1032)
2" NPT
1 1/2" NPT
3"(76.2)
70"
(1778)
Figure 1 - Dimensions in inches (mm)
