STA-RITE PoolShark GW7500 - PoolShark Repair Parts List

11
Key Part Model Model
No. Description Qty. GW7500 GW7700
• Steering Kit (Incl. Key Nos. 2,3,4) 1 GW7505 GW7515
2 Swivel Housing 1
3 Swivel 1
4 Swivel Sprocket 1
23 Clutch Clip 1
• Clutch Kit (Incl. Key Nos. 5,8,21,23) GW7503 GW7503
5 Oscillator Sleeve Bushing 1
8 Oscillator Sleeve 1
21 Clutch Assembly 1
• Gear Kit (Incl. Key Nos. 6,10,11,17,19,20) GW7504 GW7504
6 Large Steering Drive Assembly 1
10 Shaft Plug 2
11 Long Sprocket Clip 1
17 Drive Shaft Assembly 1
19 Center Sprocket 1
20 Short Sprocket Clip 1
• Oscillator Kit (Incl. Key Nos. 12, 13,14) 1 GW7502 GW7502
12 Small Sliding Seal 2
13 Oscillator 1
14 Large Sliding Seal 2
• Seal Flap Kit (Incl. Key Nos. 15,16) 1 GW7506 GW7506
15 Right Seal Flap 1
16 Left Seal Flap 1
18 Chassis with Pad 1 41201-0242 41201-0242C
• Bumper Kit (Incl. Key Nos. 24,25, 26,27,28) 1 GW7501 GW7511
24 Right Bumper Clip 1
25 Right Bumper Boot 1
26 Bumper 1
27 Left Bumper Boot 1
28 Left Bumper Boot Clip 1
• Accessory Kit 1 77705-0400 77705-0400
Includes: Regulator Valve #1 1
Regulator Valve #2 1
Regulator Valve Cover 1
Hose Connector Male/Male 1
Hose Weight 2
Short Extension Hose 1
Reducer Cone 1
Eyeball Diverter
2
Vac Port Fitting 1
• Short Leader Hose 1 GW9540 GW9540
Parts Not Available Separately:
1 Outer Housing 1
7 Support Brace 1
9 Stainless Steel Axle 1
PoolShark Repair Parts List
• Not Illustrated.
