MAINTENANCE
Electrical shock hazard. Before removing
fixture from pool wall, ALWAYS TURN OFF THE POWER
at the breaker. Installation and maintenance of this cir-
cuit, the light, light niche, and any other accessories
attached to this circuit must be performed by a licensed
electrician. The complete electrical system must be
installed, tested, and approved by a licensed electrician
before it is placed in operation.
Risk of cuts, burns, and electrical shock.
Avoid direct impacts on glass lens. Do not install dam-
aged or broken lens.
For Sunbrite
™
Lamps
See Figure 2, Page 5, for Key numbers.
1. Be sure that the power is off. Allow the lamp to cool
before re-lamping.
2. Loosen the captive leader screw (Key No. 1) from the
top of the fixture face ring (Key No. 2)
NOTICE: The screw in the face ring may be recessed.
3. Remove the lamp housing (Key No. 6) and place on
the pool deck.
4. Using a clean soft lint free cloth, carefully wipe all
sealing surfaces on the lamp housing and lens.
Replace lamp with an equivalent to the original lamp.
5. Replace the gasket (Key No. 4).
6. To reassemble the lens assembly to the lamp housing,
reverse the disassembly process. Be sure that the lamp
housing is clean, dry, and free of all traces of mois-
ture, before sealing the fixture.
7. Wind the extra cord around the lamp housing and
place the lamp housing back in the niche. Be sure to
align the locator tab at the bottom of the lamp hous-
ing with the notch in the bottom of the niche.
8. Fasten the lamp housing into the niche using the cap-
tive leader screw (Key No. 1) at the top of the trim
ring.
4
U.S. Canada Cord Length
Model Model in Feet (m)
12 Volts -
100 Watts
05501-2204 05501-2232 15 (4.5)
05501-2205 05501-2233 30 (9.1)
05501-2206 05501-2234 50 (15.2)
05501-2207 05501-2235 75 (22.8)
05501-2208 05501-2236 100 (30.5)
05501-2209 05501-2237 125 (38.1)
05501-2210 05501-2238 150 (45.7)
12 Volts -
200 Watts
05501-2211 05501-2239 15 (4.5)
05501-2212 05501-2240 30 (9.1)
05501-2213 05501-2241 50 (15.2)
05501-2214 05501-2242 75 (22.8)
05501-2215 05501-2243 100 (30.5)
05501-2216 05501-2244 125 (38.1)
05501-2217 05501-2245 150 (45.7)
120 Volts -
300 Watts
05502-1990 05502-2218 15 (4.5)
05502-1991 05502-2219 30 (9.1)
05502-1992 05502-2220 50 (15.2)
05502-1993 05502-2221 75 (22.8)
05502-1994 05502-2222 100 (30.5)
05502-1995 05502-2223 125 (38.1)
05502-1996 05502-2224 150 (45.7)
120 Volts -
500 Watts
05502-1997 05502-2225 15 (4.5)
05502-1998 05502-2226 30 (9.1)
05502-1999 05502-2227 50 (15.2)
05502-2200 05502-2228 75 (22.8)
05502-2201 05502-2229 100 (30.5)
05502-2202 05502-2230 125 (38.1)
05502-2203 05502-2231 150 (45.7)
Sunbrite
™
Large Underwater Lights
SPECIFICATIONS
