Stabila LD 320
9
EN
Technical Data
* applies for 100 % target reflectivity (white painted
wall), low background illumination, 25 ºC
** applies for 10 to 500 % target reflectivity, high back-
ground illumination, 0 ºC to + 40 ºC
*** Tolerances apply from 0.05 m to 10 m with a confi-
dence level of 95%. The maximum tolerance may
deteriorate to 0.15 mm/m between 10 m to 30 m and
to 0.2 mm/m for distances above 30 m
**** applies for 100 % target reflectivity, background
illumination of approximately 30'000 lux
Distance measurement
Typical Measuring Tolerance* ± 2.0 mm / 0.08 in ***
Maximum Measuring
Tolerance**
± 3.0 mm / 0.12 in ***
Typical Range* 50 m / 164 ft
Range at unfavourable
condition ****
40 m / 132 ft
Smallest unit displayed 1 mm / 1/16 in
Ø laser point
at distances
6 / 30 mm
(10 / 50 m)
General
Laser class 2
Laser type 635 nm, < 1 mW
Autom. laser switch off after 90 s
Autom. power switch-off after 180 s
Battery durability (2 x AAA) up to 3000 measure-
ments
Dimension (H x D x W) 100 x 54 x 30 mm
3.94 x 2.13 x 1.18 in
Weight (with batteries) 100 g / 3.21 oz
Temperature range:
- Storage
- Operation
-25 to 70 °C
-13 to 158 °F
0 to 40 °C
32 to 104 °F
Functions
Distance measuring yes
Min/Max measuring yes
Permanent measuring yes
Area yes
Volume yes
Pythagoras 2-point, 3-point
Display illumination yes
