Stagg headbanger10 - Product Information and Specifications; Product Introduction; DMX Channel Summary (7 Channels)

!
Product Introduction
• Power Supply AC90-230V, 50Hz-60Hz
• Power consumption: 80W
• 7pcs*10W RGBW LED
• DMX-Control-channels: 7 or 12, user selectable
• Color: RGBW Color-mixing
• Strobe: Flash rate: 0-10Hz
• Dimmer: 0-100%
• Maximum PAN-movement: 540
o
• Maximum TILT-movement: 270
o
• Master/Slave function
DMX Channel Summary – 7 Channels Mode
CHANNEL
VALUE
FUNCTION
1
0
Stop
1~255
Adjust Pan
2
0
Stop
1~255
Adjust Tilt
3
0~10
Close
11~255
Dimmer
4
0
Close
1~255
Red
5
0
Close
1~255
Green
6
0
Close
1~255
Blue
7
0
Close
1~255
White
