DMX Mode
With the menu button, select the DMX mode (dxxx) and press the enter key to
confirm. Then use the up and down buttons to choose the desired DMX channel (1 –
512) and press the enter key to confirm. Then use the up and down buttons to select
the desired channel mode (4, 6 or 8 channels) then press enter. Press the menu
button to return to the main menu.
DMX Channel Modes, Assignments, and Values :
4 Channels
Channel
Function
Value
CH1
RED
0~255
CH2
GREEN
0~255
CH3
BLUE
0~255
CH3
WHITE
0~255
6 Channels
Channel
Function
Value
CH1
DIMMER
0~255
CH2
STROBE
0~255
CH3
RED
0~255
CH4
GREEN
0~255
CH5
BLUE
0~255
CH6
WHITE
0~255
