Assembly and Operational Instructions
2
STEP 1: Unfold the FRONT FRAME(2) from the MAIN FRAME(1) and secure with the
LOCKING KNOB(15). Press the STAND CAPS(3) onto the stabilizers on the
MAIN FRAME(1) and the FRONT FRAME(2).
STEP 2: Bolt the ADJUSTMENT KNOB(14) into the hub on the MAIN FRAME(1).
NOTE: There are two adjustment holes on each side of the PEDAL STRAPS(12).
Select the adjustment holes which allow your feet to be easily removed from
the PEDALS(11).
CAUTION: The surface of the crank housing may
become hot during use, so allow it to cool
before moving. Read the cautions posted
on the
Folding Upper & Lower Body Cycle
.
Caution Decal
(both sides)
LOAD ADJUSTMENT
To increase the intensity of your workout, turn the ADJUSTMENT KNOB(14) clockwise.
To decrease the resistance, turn the ADJUSTMENT KNOB(14) counterclockwise.
