49 Bolt, Button Head (M8 x 1.25 x 50mm) 2
50 Bolt, Button Head (M8 x 1.25 x 55mm) 1
57 Nylock Nut (M8 x 1.25) 1
60 Washer (M8) 4
Part Number and Description Qty
43 Round Head Bolt (M6 x 1 x 15mm) 9
46 Bolt, Button Head (M8 x 1.25 x 15mm) 9
47 Bolt, Button Head (M8 x 1.25 x 25mm) 2
62 Arc Washer (M8) 6
This chart is provided to help identify the hardware used in the assembly process. Place the washers or
the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to
check the length of the bolts and screws.
NOTICE: The length of all bolts and screws, except those with flat
heads, is measured from below the head to the end of the bolt
or screw. Flat head bolts and screws are measured from the
top of the head to the end of the bolt or screw.
length
length
After unpacking the unit, open the hardware bag and make sure that you have all the following items.
Some hardware may be already attached to the part.
55 Screw, Round Head (M4 x 6mm) 2
HARDWARE IDENTIFICATION CHART
6
mm.
in.
INCHES
MILLIMETERS
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1/2 1 1/2 2 1/2 3 1/2 4 1/2 5 1/2 6
6 8 10 12
3/16" 1/4" 5/16" 3/8" 1/2"
53 Bolt, Button Head (M12 x 1.75 x 85mm) 2
54 Bolt, Button Head (M12 x 1.75 x 95mm) 2
