Technical data
Note: The specifications below are tested under the conditions of temperature 25°C+-5°C and the warm-up for
20 minutes.
Product name
DC Electronic Load
Model
Model S-LS-118
Input Rating
Power
Voltage
Current
500 W
0-150 V
0-40 A
CC Mode
Range
0-3A
0-40A
Resolution
0.1 mA
1 mA
Accuracy
±(0.05 % of set+0.045 % off.s)
CV Mode
Range
0-18V
0-150V
Resolution
0.1 mV
1 mV
Accuracy
±(0.05 % of set + 0.025 % off.s)
CR Mode
Range
0.2 Ω - 7.5 KΩ
Resolution
16 bit
Accuracy
±(0.05 % of set + 0.025 % off.s)
CW Mode
Range
500 W
Resolution
0.01 W
Accuracy
±(0.1 % of set + 0.1 % off.s)
Slope
Range
0-3A
0-40A
Rising
0.0001-0.3A/μs
0.001-2A/ μs
Falling
0.0001-0.3A/ μs
0.001-2A/μs
Voltage measurement
Range
0-18 V
0-150 V
Resolution
0.1 mV
1 mV
Accuracy
±(0.03 % of set + 0.025 % off.s)
Current measurement
Range
0-3A
0-40A
Resolution
0.1 mA
1 mA
Accuracy
±(0.05 % of set + 0.045 % off.s)
Power measurement
Range
500 W
Resolution
0.1W
Accuracy
±(0.1 % of set + 0.1 % off.s)
Over power protection
525 W
Over current protection
42 A
Over voltage protection
155 V
Over temperature protection
85°C
Input impedance
>150 KΩ
Weight
6.5kg
Dimension (W*D*H)
215 mm x 388 mm x 150.5 mm
