S
Description
Standard’s Drum Pumps are designed to
transfer a variety of materials from 55 gallon
drums and tanks. Standard Pump offers
several different pumps, each designed
for specic applications. Before operating,
please conrm that the pump’s materials of
construction are suitable for the application.
Unpacking
Cartons should be handled with care to avoid
damage from dropping, etc. After unpacking,
inspect carefully for any damage that may
have occurred during transit. Check for loose,
damaged or missing parts.
General Safety Information
The responsibility for safe assembly,
installation, and operation ultimately rests
with the operator. Read and understand ALL
safety precautions and operating instructions
before operation. Careless pump operation
can result in serious injury.
1. Before operating the pump, read and
understand these operating instructions.
2. The operator should wear suitable
protective clothing including the
following: face mask, safety shield or
goggles, gloves, apron, and safety
shoes.
3. Before operating, verify the materials
being pumped are compatible with the
pump’s “wetted components.”
4. All Federal, State, and local safety codes
should be followed.
5. Verify that the motor voltage
corresponds to proper electrical supply.
6. Before plugging motor into power
supply, make sure the motor switch is in
the OFF position. For Air Motors ensure
inlet valve is closed before attaching air
line.
7. Before operation, conrm all pump
connections are properly tightened.
8. First pump clean water in order to
familiarize yourself with the pump’s
operation, ow rate, discharge pressure
and motor speed.
9. Before starting the pump, conrm the
discharge hose is securely fastened to
the receiving vessel in order to prevent
splashing.
10. Never leave pump unattended during
operation.
11. Do not submerge the motor in any liquid.
12. When nished using the pump, ush
the pump by pumping water or an
appropriate cleaning solution. Do not
use ammable or combustible cleaning
solutions.
13. Never carry the motor by the power
cord.
14.
Never store pump in a container or drum.
Always rinse pump thoroughly and hang
on wall bracket or ensure pump tube is
stored in an upright and vertical position.
WARNING: The speed control
should not be used as the main ON/OFF
switch. Using the speed control switch in
this manner causes excessive we
ar to
the potentiometer and may result in
premature failure. The use of the speed
control switch does not cut power to the
motor and inadvertent activation could
result in injury o
r death if the motor is
a
ctivated when not properly attended
and secured. (Only applies to SP-280P
and SP-ENC Series)
Model HP Watts Max Inlet
Pressure
Min
Hose
Max
dBA
Airline Size
Inches
Hazardous
Duty
Air Consumption Shipping Wt
lbs (kg)
Air Drum Pump Motor Specication
Model Voltage Amps Watts HP Phase Hz Enclosure Variable
Speed
Hazardous
Duty
Shipping Wt
lbs (kg)
SP-410EX
2
SP-420EX
SP-280P
SP-280P-V
SP-280P-2
SP-280P-2-V
SP- NL 220 9.0 4 0
SP-ENC-V
SP-ENC-2
SP-ENC-2-V
SP-ENC
SP-ENC
NL
SP-ENC NL
SP- NL 220 9.0 4 0
1019)
The motor has thermal overlaod protection which stops the pump in case of overload. Immediately switching the motor off, position “0”, and allowing the motor to cool down.
Warning: The motor automa tically starts after cooling down, if the switch is left in position “1” (ON)
80 psi(5,5 bar)
*
*
*
*
*
*
*
*
*
WARNING: When pumping ammable
or combustible products or operating in a
hazardous duty environment, the
SP-6600/6700
or SP-7600/7700 Series
pump must be used in conjunction with
an explosion proof motor. Please contact
the factory or an authorized distributor
with any questions regarding this matter.
3
370
3/8" (10 mm)
3/4
3/4
1/2
560
560
100 psi(6,8 bar)
100 psi(6,8 bar)
3/8" (10 mm)
3/8" (10 mm)
78
87
87
1/8" NPT
1/4" NPT
1/4" NPT
Y
Y
Y
27 CFM (13 L/min) @ 80 psi (5,5 bar)
28 CFM (13,2 L/min) @ 90 psi (6,2 bar)
28 CFM (13,2 L/min) @ 90 psi (6,2 bar)
2.7 (1,2)
3.4 (1,5)
3.4 (1,5)
SP-430EX
SP-440EX
115V
230V
1000
1000
1.30
1.30
EXP (IP55)
9.1
4.4
3/4
560
100 psi(6,8 bar)
3/8" (10 mm)
87 1/4" NPT
Y
28 CFM (13,2 L/min) @ 90 psi (6,2 bar)
3.4 (1,5)
SP-A2P
WARNING: Drum Pumps are intended
for intermittent duty use. Factory
recommendation is that the pumps are
NOT operated for more than 30 minutes at
one-time. After 30 minutes of use, the
pump will need a 30 minute cool down
period. The maximum operating time
depends upon several factors including
(but not limited too) ambient temperature,
viscosity, specific gravity, and the
discharge plumbing configuration.
