Break out box connection to W3 Lightbar
Color examples:
• Blue/Amber Lightbar, Blue=1 Amber=2
• Red/Amber Lightbar, Red= 1 Amber =2
Note
Input X18 is only used during configuration and should always be set back to 0 when
configuration is done.
Function Input Additional input Cable color
Day/Night (night mode when active)
X01
X18=0
Blue/White
Reset changeable functions to default
X18=1
360° Color 1 Front
Corner light
X02
Green/White
360° Color 1 Rear Corner light
X03
Grey
Front Col
o
r 1 Emergency light (inboard modules)
X04
Black
Rear Color 1 Emergency light (inboard modules)
X05
Light Green
360° Color 2 Corner light
X06
Brown/White
Front
Color 2 Warning light
X07
Purple
Rear Color 2 Warning light
X08
X18=0
White
Change behavior if color 1&2 are activated at the
same time. Mode 0-1-2
X18=1
Turn Signal Left
X09
Black/White
Turn Signal Right
X10
Grey/White
Running light Left
X11
X22=1
Purple/White(X11)
Brake light
X22=0
Running light Right
X12
X22=1
Pink/White (X12)
Position light
X22=0
Green Warning light (Front & Rear) /Police Stop
inc Takedown
X13
X18=0
Blue
Change function on X13 between Green(default) &
Police
X18=1
Take Down (White Front Light)
X14
Green
Alley light Left
X15
Yellow
Alley light Right
X16
Orange
Work light Rear
X17
Red
Enable Config mode
X18
Pink
Airport Mode (ICAO) ***
X19
Red/White
Red Warning light (Front & Rear)
X20
X18=0
Brown
Special vehicle configuration (on negative edge):
Police SE
X18=1
Running light Center
X21
X22=1
Yellow/White (X21)
Enable Running light
X22
Orange/White
Flash Configuration (on negative edge) mode 0
-
1
-
2-3-4-5
X23
X18=1
Red/Black (X23)
Warning Light (running light)
X22=1 & X18=0
Flash Pattern select (on negative edge) Triple
-
Double-Single-Custom-ICAO
X24
X18=1
Light Green/White
(X24)
Cruise Light (on selected modules)
X18=0
!
