Standby W3 - Wiring and Connections; Wire Color Functions

W3 – Manual
WAM8W3A 4 Standby AB – standbygroup.se
Connections
Wire Functions Connect to
Black
Power supply
Good and suitable
ground
Red
Power supply
12
-
24 V DC via a 20 A
fuse
Yellow
CAN
CAN bus of a Standby
Control System or
break out box
Green
CAN
CAN bus of a Standby
Control System or
break out box
