SWIVEL HEAD FITTING INSTRUCTIONS
IMPORTANT - READ THE SAFETY WARNINGS LISTED IN THE PROSET XT3 AND PROSET XT4 INSTRUCTION
MANUAL CAREFULLY BEFORE PUTTING INTO SERVICE.
IMPORTANT - THE AIR SUPPLY MUST BE TURNED OFF OR DISCONNECTED BEFORE FITTING OR
REMOVING THE SWIVEL HEAD NOSE ASSEMBLIES.
The following procedure will allow you to assemble and t either of the swivel heads to the tool. If you order
acomplete swivel head rather than individual components, you will only need to start at step ‘L’.
All moving parts should be lubricated. Unless stated otherwise use Moly Lithium grease. Text highlighted in
grey tint refer only to the right-angle swivel head tting instructions.
Item numbers in bold refer to the components in gures 7 and 8 and the table on page 10.
Note: Nose Tips (14) Jaws (17) vary to suit specic rivet. Refer to the table 1 and Table 2 to select the correct
nose tip for the rivet being installed.
STRAIGHT SWIVEL HEAD
Fig. 7
