Stanley CS06 - Figure 5. Crosscutting Logs;Limbs with Pressure on Bottom; Figure 6. Crosscutting Thick Logs with Pressure on Bottom

16 ► CS05/CS06 User Manual
OPERATION
Figure 6. Crosscutting Thick Logs with Pressure on
Bottom
LOGS/LIMBS WITH PRESSURE ON
BOTTOM (FIGURE 5)
1. Observe all safety precautions.
2. Begin with a bottom cut. The depth of the cut should
be about 1/3 of the log diameter.
3. Finish with an upper cut, down from the top. The
saw cuts should meet.
Figure 5. Crosscutting Logs/Limbs with
Pressure on Bottom.
THICK LOGS LARGER THAN BAR
LENGTH WITH PRESSURE ON THE
BOTTOM (FIGURE 6)
1. Observe all safety precautions.
2. Begin by cutting on the opposite side of the log.
3. Pull the saw towards you and cut from the top.
4. Cut from the bottom. Make a boring cut if the log is
close to the ground.
5. Finish with a top cut.
