12
-AXÏALTITUDEÏABOVEÏMEANÏSEAÏLEVELÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏM
Spark plug: LG F6TC
SG 5500
Generator type: Synchronous
Protection type: IP 23
Continuous rated power Prated (S1): 3.6 kW
-AXIMUMÏPOWERÏ0MAXÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏK7
Rated voltage Urated: 3* 230 V~ / 400 V ~
ÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏXÏ6ÏDCÏ!
Rated current Irated: 5.2 A
Frequency Frated: 50 Hz
Drive engine design:
Single-cylinder forced air-cooled 4-stroke OHV
Displacement: 389 cm
3
Fuel type: Normal unleaded petrol
Tank capacity: 25 l
%NGINEÏOILÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏ!PPOXÏLÏ7/<0
o
C: 5W30)
Consumption at 2/3 load: 1451g/h
Weight: 91 kg
Guaranteed sound power level LWA: 97 dB(A)
Power factor cos
ij
1
Power class: G1
-AXÏTEMPERATUREÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏ#
-AXÏALTITUDEÏABOVEÏMEANÏSEAÏLEVELÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏÏM
Spark plug: LG F6TC
/PERATINGÏMODEÏ3ÏCONTINUOUSÏOPERATION
The machine can be continuously operated with the
quoted power output.
/PERATINGÏMODEÏ3ÏTEMPORARYÏOPERATION
The machine may be temporarily operated with the
quoted power output. Afterwards the machine must be
stopped for a while to prevent it from overheating
Ï,AYOUTÏ&IGÏ
1 Tank indicator
2 Fuel cap
3 230 V~ socket-outlets
4 400 V~ socket outlets (only for SG 5500)
5 12 V d.c. outlet (not for E-SG 2200)
6 Earth connection
7 Overload cut-out
8 Voltmeter (not for E-SG 2200)
9 Oil drain plug
Ï/ILÏlLLERÏPLUG
11 Oil shortage cut-out
12 On/Off switch
13 Choke lever
14 Pull cord
15 Electro starter (only for E-SG 4000, SG 4200 and SG
5500)
16 Petrol cock
17 Wheels (only for SG 3000, SG 4200 and SG 5500)
18 Carry handle
19 Rubber feet (not for SG 2200, E-SG 2200 and E-SG
4000)
20 Battery (only for SG 4200 and SG 5500)
21 Transport handles
Ï/ILÏlLLERÏSET
23Spark plug wrench set
24 Push bar assembling set ( not for E- SG 2200, E-SG
4000 and SG 2200)
25 Wheel assembling set ( not for E SG 2200, E- SG 4000
and SG 2200)
26 Spanner
27 DC oulet adapter cable
Ï!IRÏlLTERÏSET
29 Spark plug
Ï-UFmER
31 230 V~ / 400V ~transfer switch ( for SG 5500 only)
Ï4RANSPORTÏHANDLEÏlXINGÏKNOBÏÏNOTÏFORÏ%3'ÏÏ%3'
4000 and SG 2200)
33 Electro starter key
Ï"EFOREÏPUTTINGÏTHEÏMACHINEÏINTOÏOPERATION
Ï7HEELÏASSEMBLYÏONLYÏFORÏ3'ÏÏ3'ÏÏANDÏ
3'ÏÏlGÏ
1. First place one end of the bolt (item 25) through the
hole in the frame and secure it with a nut and washer.
2. Put the socket through the another end of bolt (item
25) and place the wheel, washer and secure it with the
nut.
3. Place the wheel cover and secure it via clip as
designed on the innder side of cover.
4. Assemble the left side wheel with same prodcedure
Ï,A
Y
OUTÏ&I
G
Ï

Ï"EFOREÏ
P
UTTIN
G
ÏTHEÏMACHINEÏINTOÏO
P
ERATIO
N
G
B
