32
Put the
SA
Jaw Pusher through
the Jaw Pusher
Spring.
Tighten th
e Jaw Guide, with Ja
ws, to the
Pulling Head,
with pulling Jaw C
ase Lock, by
hand until it
stops.
Turn bac
k a little until the rotation
is locked by
the boss of the
Jaw Case Lock.
Jaw Pusher Spring
SA Jaw Pusher
Jaw Guide
Jaw Case Lock
Pulling Head
Jaw Case Lock
Jaw Guide
Lock
32
34
