u Check for damage to the tool, parts or accessories
which may have occurred during transport.
u Take the time to thoroughly read and understand this
manual prior operation.
FEATURES (FIG.C)
This tool includes some or all of the following features.
1. On/Off switch
2. Forward/reverse selector
3. Mode selector
4. Depth stop
5. Tool holder
6. Side handle
7. Battery
20. LED work light
21. Battery fuel gauge
ASSEMBLY
Use
Warning! Let the tool work at its own pace. Do not
overload.
Charging the battery (g. A)
The battery needs to be charged before rst use and
whenever it fails to produce sufcient power on jobs that
were easily done before. The battery may become warm
while charging; this is normal and does not indicate a
problem.
Warning! Do not charge the battery at ambient
temperatures below 10 °C or above 40 °C. Recommended
charging temperature: approx. 24 °C.
Note: The charger will not charge a battery if the cell
temperature is below approximately 10 °C or above 40 °C.
The battery should be left in the charger and the charger
will begin to charge automatically when the cell
temperature warms up or cools down.
u To charge the battery, insert the Battery (7) into the
charger (9). The battery will only t into the charger
one way.
u Plug the charger (9) into a suitable power source and
switch on.
u
Charge discharged batteries within 1 week. Battery life
will be greatly diminished if stored in a discharged state.
Fitting and removing the battery (g. B)
u To t the battery, line it up with the receptacle on the
tool (11). Slide the battery into the receptacle and push
until the battery snaps into place.
u To remove the battery, push the release button (12)
and remove the battery from the receptacle.
Fitting the side handle (g. C)
u Turn the grip counterclockwise until you can slide the
side handle (6) onto the front of the tool as shown.
u Rotate the side handle into the desired position.
u Tighten the side handle by turning the grip clockwise.
Fitting and setting the depth stop (g. C)
u Depress the button (8).
u Insert the depth stop (4) into the mounting hole as
shown.
u
Set the depth stop (4) to the desired position. The
maximum drilling depth is equal to the distance between
the tip of the drill bit and the front end of the depth stop.
u Release the button (8).
Fitting an accessory (g. D - E)
u Clean and grease the shank (13) of the accessory.
u Pull back the sleeve (14) and insert the shank into the
tool holder (5).
u Push the accessory down and turn it slightly until it ts
into the slots.
u Pull on the accessory to check if it is properly locked.
The hammering function requires the accessory to be
able to move axially several centimetres when locked
in the tool holder.
u To remove the accessory, pull back the sleeve (14)
and pull out the accessory.
Keyed chuck (g. F)(Optional)
u
Open the chuck by turning the sleeve (15) anti-clockwise.
u Insert the bit shaft (17) into the chuck.
u Insert the chuck key (18) (Optional) into each hole (16)
in the side of the chuck and turn clockwise until tight.
Warning! Before drilling into walls, oors or ceilings,
check for the location of wiring and pipes.
Warning! Do not apply chisels when the tool is in the
drilling mode.
Switching on and off (g. G)
u To switch the tool on, press the on/off switch (1).
u To switch the tool off, release the on/off switch.
Forward/reverse action (g. H)
u Move the selector (2) to indicate the direction you
require.
Selecting the operating mode (g. I)
The tool can be used in three operating modes.
u To operate the operating mode selector (3), push the
unlock button (22) and rotate the selector towards the
required position, as indicated by the symbols.
