Stanley SPL3 User Manual

8
STHT77342
Contents
• UserSafety
• Contents
• ProductOverview
• Keypad,Modes,andLED
• Applications
• BatteriesandPower
• SetUp
• Operation
• AccuracyCheckandCalibration
• Specications
User Safety
WARNING:
• CarefullyreadtheSafety InstructionsandProduct
Manual beforeusingthisproduct.Theperson
responsiblefortheinstrumentmustensurethatall
usersunderstandandadheretotheseinstructions.
CAUTION:
• Whilethelasertoolisinoperation,becarefulnot
toexposeyoureyestotheemittinglaserbeam
(redlightsource).Exposuretoalaserbeamforan
extendedtimemaybehazardoustoyoureyes.
CAUTION:
• Glassesmaybesuppliedinsomeofthelasertool
kits.TheseareNOTcertiedsafetyglasses.These
glassesareONLYusedtoenhancethevisibilityof
thebeaminbrighterenvironmentsoratgreater
distancesfromlasersource.
Retainallsectionsofthemanualforfuturereference.
WARNING:
• Thefollowinglabelsamplesareplacedonyourlaser
tooltoinformofthelaserclassforyourconvenience
andsafety.PleasereferencetheProduct Manual
forthespecicsonaparticularproductmodel.
Complies with 21 CFR 1040.10 and 1040.11
except for deviations pursuant to Laser
Notice No. 50, dated June 24, 2007.
Product Overview
Figure A - LaserTool
1. 1/4-20threadedmount
2. LaserWindow
3. Power/PendulumLockSwitch
4. SlotsforQuickLinkBracketConnect
5. LED/Out-of-LevelIndicator
Figure B - LaserToolBatteryLocation
6. 2xAABatteries
7. BatteryCover
Figure C - Power/TransportLock
Figure D - LaserModes
Figure E - QuickLinkBracketAssembly.
9. QuickLinkBracket
Figure F - QuickLink ™ BracketDetail
Figure M -VerticalBeamAccuracy
Figure N -HorizontalBeamAccuracy
IEC/EN60825-1
LASER RADIATION - DO NOT
STARE INTO THE BEAM
CLASS 2 LASER PRODUCT
Max Output ≤ 1 mW @ 630-680 nm
ENGLISH

Stanley SPL3 Specifications

General

Brand	Stanley
Model	SPL3
Category	Laser Level
Language	English
