Stanley V Series - TECHNICAL REQUIREMENTS; HTMA; EHTMA REQUIREMENTS

SKV20 User Manual ◄ 8
HTMA /
EHTMA REQUIREMENTS
HTMA
TOOL TYPE
HYDRAULIC SYSTEM REQUIREMENTS
TYPE I TYPE II
TYPE RR
TYPE III
Flow Range
4-6 gpm 7-9 gpm 9-10.5 gpm 11-13 gpm
(15-23 lpm) (26-34 lpm) (34-40 lpm) (42-49 lpm)
Nominal Operating Pressure
1500 psi 1500 psi 1500 psi 1500 psi
(at the power supply outlet)
(103 bar) (103 bar) (103 bar) (103 bar)
System relief valve setting
2100-2250 psi 2100-2250 psi 2200-2300 psi 2100-2250 psi
(at the power supply outlet)
(145-155 bar) (145-155 bar) (152-159 bar) (145-155 bar)
Maximum back pressure 250 psi 250 psi 250 psi 250 psi
(at tool end of the return hose) (17 bar) (17 bar) (17 bar) (17 bar)
Measured at a max. fluid viscosity of: 400 ssu* 400 ssu* 400 ssu* 400 ssu*
(at min. operating temperature) (82 centistokes) (82 centistokes) (82 centistokes) (82 centistokes)
Temperature: Sufficient heat rejection 140° F 140° F 140° F 140° F
capacity to limit max. fluid temperature to: (60° C) (60° C) (60° C) (60° C)
(at max. expected ambient temperature)
Min. cooling capacity at a temperature 3 hp 5 hp 6 hp 7 hp
difference of between ambient and fluid (2.24 kW) (3.73 kW) (5.22 kW) (4.47 kW)
temps 40° F 40° F 40° F 40° F
NOTE: (22° C) (22° C) (22° C) (22° C)
Do not operate the tool at oil temperatures above 140° F (60° C). Operation at higher temperatures can cause operator
discomfort at the tool.
Filter
25 microns 25 microns 25 microns 25 microns
Min. full-flow filtration
30 gpm 30 gpm 30 gpm 30 gpm
Sized for flow of at least:
(114 lpm) (114 lpm) (114 lpm) (114 lpm)
(For cold temp. startup and max.
dirt-holding capacity)
Hydraulic fluid Petroleum based
100-400 ssu* 100-400 ssu* 100-400 ssu* 100-400 ssu*
(premium grade, anti-wear, non-conductive)
(20-82 centistokes)
Viscosity (at min. and max. operating temps)
NOTE:
When choosing hydraulic fluid, the expected oil temperature extremes that will be experienced in service determine the
most suitable temperature viscosity characteristics. Hydraulic fluids with a viscosity index over 140 will meet the requirements
over a wide range of operating temperatures.
*SSU = Saybolt Seconds Universal
EHTMA
HYDRAULIC SYSTEM
REQUIREMENTS
CLASSIFICATION
B
C
D
Flow Range
Nominal Operating Pressure
3.5-4.3 gpm
(13.5-16.5
lpm)
1870 psi
4.7
-5.8 gpm
(18
-22 lpm)
1500 psi
7.1-8.7 gpm
(27-33 lpm)
1500 psi
9.5
-11.6 gpm
(36
-44 lpm)
1500 psi
11.8-14.5 gpm
(45-55 lpm)
1500 psi
(at the power supply outlet)
(129 bar)
(103 bar)
(103 bar)
(103 bar)
(103 bar)
System relief valve setting
2495 psi
2000 psi
2000 psi
2000 psi
2000 psi
(at the power supply outlet)
(172 bar)
(138 bar)
(138 bar)
(138 bar)
(138 bar)
NOTE: These are general hydraulic system requirements. See tool specification page for tool specific requirements
