-2-
CAUTION: Take extreme caution not to over tighten the screws!!! Over tightening
of the screws can strip the holes.
1. After the light has been mounted (see separate mounting instructions), if adjustments
permit, slide the light forward until the top of it is touching the windshield.
2. Loosen the baffle screws and carefully slide the baffle forward until the gasket is forced
slightly downward by the pressure of the windshield.
3. Tighten the Baffle Adjusting Screws to secure the baffle in place .
Baffle Adjustment
4. Once all of the brackets are securely tightened, check your mount to ensure the
desired angle is achieved. Stand in front of the vehicle and inspect the light through
the front windshield. The screws may be loosened slightly to allow for any final
adjustments necessary.
