8 SERVICE REPLACEMENTS AND JAW ASSEMBLIES
Part No
Diag No
Description
B018007
1
65mm Barrier Tape
E024002
2
6mm Element Ribbon
B017002
B017007
3
9.5mm Silicone Rubber
9.5mm Silicone Sponge
M202005
4
Expansion Block (Pair)
M202004
5
9mm Brass Shim
B021005
6
Compression Spring
B022002
7
Ball bearing
B023004
8
1 ½” Roll Pin
B029002
9
Allen Key
M202009
10
Loading Pin
B018022
11
9mm S/A Backing Tape
E019005
12
Thermocouple
B017014
NA
Silicone Rubber Compound (85g)
B021007
NA
Gas Strut
JAW ASSEMBLIES
HEATED JAW WITH HEATED JAW UNHEATED JAW
THERMOCOUPLE
1
2
3
4
8
5
6
7
9
10
1
1
2
2
3
11
3
12
3
1
