Star BG3 - PARTS LIST

8
PARTS LIST November 12, 2014, Rev E
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE 1
INCLUDE MODEL AND SERIAL NUMBER OF 1
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description and Model Designation
Part
Number
Key
Number
MODEL BG3 PORTABLE GRIDDLE
1 D9-30-GR-0055 1 GRIDDLE PLATE
2 2N-05-GR-0001 2 ELEMENT - 120V/208V/230V (875W) (square, new style)
3 D9-04-GR-0017 2 PLATE - ELEMENT
4 D9-04-GR-0012 1 CLAMP - THERMOSTAT BULB (not shown)
5 D9-06-GR-0002 1 INSULATION (not shown)
6 D9-50-GR-0060 1 GRIDDLE PLATE HOUSING ASSEMBLY
7 D9-04-GR-0060 2 GUIDE - GREASE PAN
8 D9-04-GR-0010 1 GREASE PAN
9 D9-70-GR-0020 2 SUPPORT - GRIDDLE PLATE HOUSING
10 2A-06-07-0044 4 FOOT - NEOPRENE w/WASHER
11 D9-04-GR-0015 1 BASE
12 D9-04-GR-0016 1 BACK FRAME
13 2E-05-07-0057 1 TERMINAL BLOCK
14 B9-04-WB-0211 1 MOUNT, TERMINAL BLOCK
15 2T-05-GR-0005 1 THERMOSTAT
16 2R-09-07-0006 1 KNOB - THERMOSTAT
17 2S-Z3823 1 PILOT LIGHT - 120V
17 2S-05-07-0138 1 PILOT LIGHT - 208/230V
18 2C-Z1675 2 ROLL PIN
19 D9-50-GR-0218 1 LEFT TUBE SUPPORT ASSEMBLY
21 B9-04-WB-0065 1 REAR PLATE, CORD BUSHING
22 D9-04-GR-0013 1 COVER - BACK
23 2K-05-07-0017 1 GROMMET - LEAD IN CORD
24 2E-Z2935 1 CORD SJTO 14/3 NEMA 5-15P 120V
24 2E-Z2770 1 CORD, POWER, 14-3 6-15 208/240V
25 2M-Z9176 1 OPERATIONS LABEL
NI D9-30-GR-0130 1 BURNGUARD (some models)
Star Manufacturing International, Inc.
