PLATE COMPACTOR
2
Specifications
INTRODUCTION
Introduction 2
Specifications 2
Symbols 3
Safety 3
General Safety Rules 3
Specific Safety Rules 5
Contents Supplied 6
Assembly 7
Know your Compactor 9
Features & Controls 9
Compactor Operation 10
Maintenance 12
Storage 15
Lifting/Transporting 16
Trouble Shooting 17
Parts Schedule 18
Parts List 19
Your new Vibratory Plate Compactor will
more than satisfy your expectations. It has
been manufactured under stringent quality
standards to meet superior performance
criteria. You will find it easy and safe to
operate, and with proper care, it will give you
many years of dependable service.
Carefully read through this entire
operator’s manual before using
your new Plate Compactor. Take
special care to heed the cautions
and warnings.
These compactors are not intended
to be used on cohesive soils such
clay or hard surfaces like concrete.
The commitment to quality has been designed
into details: reinforced self-cleaning base
plate, engine oil drain hose, closed V-belt
guard, self-adjusting centrifugal clutch and
folding handle. A range of useful accessories
enables use in all kinds of applications.
The Plate Compactor applies energy to the
loose soil or other materials to increase its
density and load bearing capacity, mainly used
for small repair and maintenance work. The
loose soil or particles are moved or rearranged
in a particular manner close to each other to
The Engine Manufacturer is responsible for
all engine-related issues with regards to
performance, power rating, specifications,
warranty and service. Please refer to the
Engine Manufacturer’s owner/operator’s
manual, packed separately with your unit, for
more information.
Item No. 61021
Plate Size 540 X 450 mm
Centrifugal Force 20000 N
Exciter Speed 5500 vpm
Compaction Speed 30 cm
Travel Speed 25.5 m/min
Engine 196cc, 4.1 kW
Operation Weight 96 kg
RECYCLING AND DISPOSAL
This marking indicates that this
product should not be disposed with
other household wastes. To prevent
possible harm to the environment
or human health from uncontrolled
waste disposal, recycle it responsibly
to promote the sustainable reuse of
material resources. To return your
used device, please use the return
and collection systems or check with
your local authority or local stores
for advice of environmental safe
recycling.
avoid any trapped air or voids. It increases
the load bearing capacity, decreases water
seepage, prevents soil settlement, reduces
swelling, contraction of the soil and prevents
frost damage. It is ideal for compaction
of granular soils, sands, gravel, crushed
aggregate and mixed soils.
