Stark 61021 - Parts Information; Contents Supplied

PLATE COMPACTOR
6
The plate compactor comes partially assembled
and is shipped in carefully packed two boxes.
After all the parts have been removed from the
carton, you should have:
1. Exciter and Chassis assembly
2. Belt
3. Engine with Frame Assembly
4. Belt Cover
5. Handle
6. Wheel Bracket Assembly
7. Operator’s Manual & Engine Manual
8. Hardware Bag, Including
CONTENTS SUPPLIED
X 2
A
Ø12 X 4
M8 x 45 X 2
B
M5 x 35 X 1
C
X 2
D
Ø12 X 4
BOX 1
BOX 2
1
2
3
4
8
6
7
5
