Operating Instructions & Parts Manual
Page 4
Example of Weight installation
Adding Oil to the Handle Buffer
When moving the Load/Unload handle and you feel it make fast hard contact
or hear a suction noise then its time to check the oil buffer.
On the left side of the machine (when standing in front of it) there is a small
metal access plate held on by 2 small screws. Remove the screws and plate to
expose the valve and reservoir.
Push the Load/Unload handle towards the back of the machine. Remove the
screw #25 and carefully add high grade hydraulic oil into the hole.
Begin pulling/pushing the Load/Unload handle back and forth until any
suction noise has disappeared.
Replace screw #25. Replace access plate.
