STARTRITE 352E - 6.5 Assembly of the 352 E Legstand

2
1
7
65
4
3
8
9
10 11
12
13
PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com
Joint panel
Hex. Bolt M8X16
Locknut M6
Flat washer 6
Flange nut M6
Left panel
Hex. Bolt M6X45
Flat washer 8
Spring washer
Hex. Nut M8
Hex. Bolt M8X20
Support bracket
Right panel
1
2
3
4
5
6
7
8
9
10
11
12
13
Ref No. Description
38 39
6.5 ASSEMBLY OF THE 352E LEGSTAND
Ref No. Description
1 Joint panel
2 Hex. Bolt M8X16
3 Locknut M6
4 Flat washer 6
5 Flange nut M6
6 Left panel
7 Hex. Bolt M6X45
8 Flat washer 8
9 Spring washer
10 Hex. Nut M8
11 Hex. Bolt M8X20
12 Support bracket
13 Right panel
10 11
