1. General Information
1.1 FOREWORD
This manual must be read and understood before operating the machine. This will provide a better working knowledge of the machine, for increased safety
and to obtain the best results.
2. Machine Description
2.1 MACHINE IDENTIFICATION
There is a specification label fixed to the machine, containing the manufacturer's data, year of construction,
serial number and blade data.
2.2 TECHNICAL SPECIFICATION
SPECIFICATION 502E 502E 352E 352E
(Phase) (Single Phase) (Three Phase) (Single Phase) (Three Phase)
Throat depth mm 465 465 345 345
Blade Speed m/min 1000 1000 1000 1000
Motor Power output W 2450 2300 2000 1900
Cutting Depth (mm) 335 335 250 250
Table Tilt 0-20º 0-20º 0-20º 0-20º 0-20º
Table Height mm 950 950 1040 1040
Blade Length mm 3810 3810 2845 2845
Blade Width mm 10-35 10-35 6-25 6-25
Nett Weight kg 200 200 125 125
Size mm W990 x D680 x H1970 W990 x D680 x H1970 W820 x D660 x H1835 W820 x D660 x H1835
Power Supply 230V / 50Hz 400V / 50Hz 230V / 50Hz 400V / 50Hz
Full Load Current A 10.62 4.68 9.41 4.16
Max Short Circuit Current A 1000 1000 1000 1000
2.3 RECOMMENDED PROTECTIVE CLOTHING
• Gloves for moving work material and when carrying out the blade changes;
• Non-slip shoes;
• Protective eye glasses.
2.4 NOISE EMISSION
The measurements of noise, in the working position and during operation, were carried out under the standard ISO 7960 annex "J":
Instantaneous acoustic pressure: (Constant K4 dB measured in accordance with EN150 3746: 1995)
Sound power level (no load) <90 dB(A)
Sound power level (load) <100 dB(A)
Sound Pressure level (no load) <80 dB(A)
Sound Pressure level (load) <90 dB(A)
The figures quoted are emission levels and are not necessarily safe working levels. Whilst there is a correlation between the emission and exposure
levels, this cannot be used reliably to determine whether or not further precautions are required. Factors that influence the actual level of exposure of the
workforce include the characteristics of the work room and the other sources of noise etc. i.e. the number of machines and other adjacent processes. Also
the permissible exposure level can vary from country to country. This information, however, will enable the user of the machine to make a better evaluation
of the hazard and risk.
