Statesman CHM90SS - Installation

Feature
• Thecookerhoodismadeofhighqualitymaterialsinastreamlineddesign.
• Equippedwithhighpowerandlownoiseelectricmotor,thecookerhoodproduces
 strongsuctionandlownoise.
• Specialwindtunnelconstruction,freedirtwillbeabsorbedinasecond.
Installation
• Thecookerhoodshouldbeplaces65-75cmabovethecooking
 planeforsafeandeffectiveuse.seeFig.1
• Theremustbeadequateventilationoftheroomwhenthe
 cookerhoodisworking.
• Fixtheoutletonthemotorbox.SeeFig2
• Drill3holeswithadiameterof8mmtoaccommodate
 thebracket,andtheholesmustbealigned.
• Insertscrewsintotheholesandtighten.
• Fixthedrillingtemplate.SeeFig3
• Hangthecookerhoodonthebracket.SeeFig4
• Fixanextrascrewtopreventthecookerhoodinadvertently
 slidingoffthebracket.SeeFig5
