Statesman ESH60SS - Fixing the Hob to the Worktop; Attaching Fixing Brackets; Securing the Hob

Fastening the Fixing Brackets
The unit should be placed on a stable, smooth surface (use the packaging).
1. Turn the hob upside down and fasten the brackets to the appropriate holes.
DO NOT tighten the screws at this stage.
2. Apply sealing strips around the edge of hob.
3. Insert the hob into the cut out and position it correctly.
4. Tighten the screws to secure the hob to the worktop.
• The hob must be installed by qualied personnel or technicians.
• Do not mount above cooling equipment, dishwashers and rotary dryers.
• Surfaces around the hob should be able to withstand heat generated by hob.
• Never use a steam cleaner to clean the hob.
• Do not use a silicon sealant to seal the appliance against the aperture. This will make it
difcult to remove hob from the aperture, particularly if servicing is required.
Do not over-tighten the hob
clamps as distortion of the
hob may occur.
