4.2.2.1 SENSOr ( Type of sensor connected )
This parameter defines the type of electrical sensor connected.
There are four options.
currnt ( Current inputs, internally generated loop )
tc ( Thermocouple input )
VoltS ( Voltage input, including millivolts )
rtd ( Resistance thermometer )
default setting: currnt
4.2.2.2 rANgE ( electrical range for voltage or
current inputs)
This Range parameters will only be available if the sensor option has been set to either
current or voltage. The options available will vary between these two settings.
4.2.2.2.1 rANgE [ SENSOr=currnt ]
If the sensor type has been set to current, the following options are available.
4-20 ( Internally generated 4-20mA )
0-20 ( Internally generated 0-20mA )
0-10 ( Internally generated 0-10mA )
default setting: 4-20.
4.2.2.2.2 rANgE [SENSOr=VOLtS]
If the sensor type has been set to voltage, the following options are available.
0.100 ( 100mV on the millivolt input )
1 ( 1 Volt on the voltage input )
1-5 ( 1 to 5 volts on the voltage input )
10 ( 10 volts on the voltage input )
default setting: 0.100
INPUT MENU
PROGRAMMING
Page 37
