4.2.2.3 SENSOr ( Type of thermocouple )
This menu option is only available if a thermocouple has been selected as sensor type.
This option allows the user to set the thermocouple type. The options are:-
CA ( K type thermocouple )
J ( J type thermocouple )
t ( T type thermocouple )
r ( R type thermocouple )
S ( S type thermocouple )
E ( E type thermocouple )
F ( F type thermocouple )
n ( N type thermocouple )
b ( B type thermocouple )
Default setting: CA.
4.2.2.4 UnitS ( Temperature sensor units )
This item is only available if a temperature sensor has been selected, that is, either a
thermocouple or an RTD. The two options are:-
dEg C ( Degrees Centigrade )
dEg F ( Degrees Fahrenheit )
Switching between these two has the effect of changing the engineering range between
Degrees centegrade and Degrees Fahrenheit.
Default setting: dEg C.
INPUT MENU
PROGRAMMING
Page 38
