Technical Information
Service Manual
Model
SC-36ZPL-HP230
Product Code CB432010100
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 33000(8800~40900)
Heating Capacity(Min~Max) Btu/h 34600(16700~49400)
Cooling Power Input(Min~Max) W 3220(500~4100)
Heating Power Input(Min~Max) W 3100(1000~7000)
Cooling Power Current A 14.7
Heating Power Current A 14.2
Rated Input W 7000
Rated Current A 19
Rated Heating Current A 30
Air Flow Volume(SH/H/M/L) CFM 824/706/589/441
Dehumidifying Volume Pint/h 7.4
EER (Btu/h)/W 10.25
COP (Btu/h)/W 11.16
SEER 23
HSPF 10.5
Application Area yd
2
55.01-83.72
Indoor Unit
Model of indoor unit
SC-36WPL-HP230
Indoor Unit Product Code CB432N10100
Fan Type Cross-flo
Diameter Length(DXL) inch Φ4 1/4X20 9/16
Fan Motor Cooling Speed (SH/H/M/L) r/min 1550/1300/1150/850
Fan Motor Heating Speed (SH/H/M/L) r/min 1500/1300/1150/1000
Output of Fan Motor W 70
Fan Motor RLA A 0.4
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ9/32
Row-fin Ga inch 2-1/16
Coil Length (LXDXW) inch 42 9/32X1X15
Swing Motor Model MP24BA
Output of Swing Motor W 2
Fuse A 5
Sound Pressure Level (SH/H/M/L) dB (A) 54/49/44/37
Sound Power Level (SH/H/M/L) dB (A) 64/59/54/47
Dimension (WXHXD) inch 53 9/64X12 53/64X9 61/64
Dimension of Carton Box (LXWXH) inch 56 39/64X16 29/64X13 55/64
Dimension of Package (LXWXH) inch 56 47/64X16 37/64X14 7/16
Net Weight Ib 41.9
Gross Weight Ib 51.8
