Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit
SC-36ZPL-HP230
Outdoor Unit Product Code CB432W10100
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXAW-F518zX440C
Compressor Oil FV50S or equivalent
Compressor Type Rotary
Compressor Locked Rotor Amp (L.R.A) 36
Compressor RLA A 24
Compressor Power Input W 5830±3%
Overload Protector /
Throttling Method Electron expansion valve
Operation temp ºF 61~86
Ambient temp (cooling) ºF 0~109
Ambient temp (heating) ºF -31~75
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ5/16
Rows-fin Ga inch 2-1/16
Coil Length (LXDXW) inch 41 37/64X1 1/2×38 13/64
Fan Motor Speed rpm 940
Output of Fan Motor W 170
Fan Motor RLA A 0.73
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit CFM 3119
Fan Type Axial-flo
Fan Diameter inch Φ21 21/32
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Design Pressure(High) PSIG 550
Design Pressure(Low) PSIG 240
Sound Pressure Level (H/M/L) dB (A) 63/-/-
Sound Power Level (H/M/L) dB (A) 73/-/-
Dimension (WXHXD) inch 43 37/64X43 1/2X16 9/64
Dimension of Carton Box (LXWXH) inch 45 1/2X18 57/64X45 39/64
Dimension of Package (LXWXH) inch 45 39/64X19 X44 9/32
Net Weight Ib
253.53
Gross Weight Ib 271.17
Refrigerant R410A
Refrigerant Charge oz 123.5
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.3
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 5/8
Max Distance Height ft 98.4
Max Distance Length ft 164
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
