Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
QtySC-36ZPL-HP230
Product Code CB432W08100
1 Front Grill 1473050 1
2 Cabinet 0143500401P
1
3 Front Side Plate 01303249P
1
4 Axial Flow Fan 10335014
1
5 Drainage Plug 7671301802
1
6 Chassis Sub-assy 0280319605
1
7 Drainage Connecter 06123401
1
8 Compressor Gasket 76713066
3
9 Compressor and fitting 205200003
1
10 Electrical heater 7651000413
1
11 Magnet Coil 4300040029
1
12 4-way Valve Assy 30152000213
1
13 Right Side Plate 0130504402P
1
14 Valve Support Sub-Assy 0171501201P
1
15 Cut-off Valve 07130239
1
16 Valve cover 22245003
1
17 Retaining plate 02115006P 1
18 Handle assy 2113109 1
19 Wiring clamp 26115004 1
20 Electronic expansion valve Sub-Assy 07133684
1
21 Temperature Sensor 3900031001
1
22 Rear Grill 01475013 1
23 Condenser Assy 01163491 1
24 Clapboard 01233134
1
25 Condenser support plate 01175037 1
26 Motor Support Sub-Assy 01802876 1
27 Top Cover Sub-Assy 1255007 1
28 Electric Box Cover 01425281
1
29 Reactor 43130192 2
30 Electric Box Sub-Assy 02603620 1
31 Pass wire ring sub-assy 76614102 2
32 left handle 2113031
1
33 Left Side Plate 01305043P 1
34 Fan Motor 1570280000405 1
35 Electric Box Cover 01425281 1
36 Main Board 300027000216
1
37 Electric Box 02603614 1
38 Radiator 49010252 1
39 Terminal Board 42200006001401 1
40 Electric Box Assy 100002001028 1
41 Electrical Heater (Chassis) 7651000413 1
78
