Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
VIR36HP230V1BO LIVV36HP230V1AO
Product Code CB171W10800 CB432W23000
1 Front Grill
01473050 016004060005
1
2 Cabinet
0143500401P 0143500401P
1
3 Front Side Plate
01303249P 01303249P
1
4 Axial Flow Fan
10335014 10335014
1
5 Drainage Plug
7671301802 /
1
6 Chassis Sub-assy
02803026P 017000060476
1
7 Drainage Connecter
06123401 /
1
8 Compressor Gasket
76710207 009012000004
3
9 Compressor and fitting
00205275 00900100019501
1
10 Electrical heater
7651873209 /
1
11 Magnet Coil
4300040029 4300040045
1
12 4-way Valve Assy
03123890 030152000329
1
13 Right Side Plate
0130504402P 0130504402P
1
14 Valve Support Sub-Assy
0171501201P 0171501201P
1
15 Cut-off Valve
07133157 07133157
1
16 Valve cover
22245003 22245003
1
17 Retaining plate 02115006P 02115006P
1
18 Handle assy 02113109 02113109
1
19 Wiring clamp 26115004 26115004
1
20
Electronic expansion valve
Sub-Assy
07133684 030174060043
1
21 Temperature Sensor
3900031001 3900030901
1
22 Rear Grill 01475013 01475013
1
23 Condenser Assy
01163491 011002061052
1
24 Clapboard 01233134 01175092
1
25 Condenser support plate 01175037 01175092
1
26 Motor Support Sub-Assy 01802876 017012000017
1
27 Top Cover Sub-Assy
01255007 000051060049
1
28 Electric Box Cover 01425281 20125002
1
29 Reactor 43130192 /
2
30 Electric Box Sub-Assy 02603620 100002068354
1
31 Pass wire ring sub-assy
76614102 /
2
32 left handle 02113031 02113031
1
33 Left Side Plate 01305043P 01305043
1
34 Fan Motor 1570280000405 15010400000102
1
35 Electric Box Cover 01425281 20125002
1
36 Main Board 30138000711 300027060993
1
37 Electric Box 02603614 20115003
1
38 Radiator 49010252 4901521502
1
39 Terminal Board 42200006001401 42200006001401
1
40 Electric Box Assy 10000100328 100002068354
1
41 Electrical Heater (Chassis) 7651000413 /
1
