Stealth SC-30CC-UM - System Schematic

System Schematic
Indoor unit
System Components*
1. Indoor Power Supply
2. Drain Pipe
3.
Communication Cable
4. Decorative Discharge Air
Grille (Included)
5. Refrigeration Pipes
6. Tether Controller (Sold
Seperately)
7. Remote Controller
8. Service Cover
9. Communication Cable
10. Front Panel
11. Outdoor Power Supply
12. Liquid Pipe
13. Gas Pipe
14. Drain Hose
Outdoor Unit
Air outlet
Air inlet
1
2
5
4
3
67
6
Air outlet
Air inlet
14 12 1110
The refrigerant pipe, drain pipe and electrical wiring for this unit should be installed by a
qualified HVAC professional only.
CAUTION
98
13
*Not all items included in
equipment purchase
