STEINEL HL 2010 E - Spare Parts Lists and Wiring Diagrams; Spare Parts List HL 1610 S; Wiring Diagram HL 1610 S

- 10 -
English
Tool elements / spare parts list HG 2310 LCD
Spare Parts List HL 1610 S
1
11
9
10
2
7
3
8
6
5
4
Part No.
Pos.
HL 1610 S, Type 3480
Housing Set incl. Labels
Switch with Markings (external)
Power Cord with Strain Relief
Power Cord Connector
Set of 5 Housing Screws
PCB/IC Block with Switch (internal)
Motor/Fan Assembly
Heating Element 1300W/120V
Switch (internal)
02816
02416
02723
—
02829
02316
02216
02116
02417
1+2
3
4+5
6
7
8
9
10
11
blue
red
violet
yellow
red
white
black
Wiring Diagram HL 1610 S
