10. Technical specifications
Dimensions L630LED: 364 × 211 × 65
L631LED: 364 × 61 × 65
Voltage supply 220-240 V / 50 Hz
Power consumption 8.2 W LED
Luminous flux 663 lm
Eciency 80.8 lm/W
Colour temperature 3000 K (warm white), SDCM 3
Colour rendering index Ra ≥ 80
Lamp life expectancy 50,000 hours (L70B10 to LM80)
Sensor technology Passive infrared
Angle of coverage 360° with 90° angle of aperture and sneak-by guard
Reach 8 m tangential
Time setting 5s - 15min
Twilight setting 2-2000 lux
Programme setting 4 programmes geared to practical needs
Manual override
(permanent light)
selectable, 4 h
Prerequisite: switch or break-contact button in mains power supply lead
Temperature range -20° to +50°C
IP rating IP 44
Protection class I
Impact resistance IK07
11. Troubleshooting
Malfunction Cause Remedy
Sensor-switched light
without power
■ Fuse faulty, not switched ON,
break in wiring
■ Short circuit
■ Fit new fuse, turn ON mains
switch, check lead with voltage
tester
■ Check connections
Sensor-switched light will
not switch ON
■ Twilight setting in night-time
operation during daytime
operation
■ Mains switch OFF
■ Fuse blown
■ Detection zone not correctly
adjusted
■ Mains terminal not connected
properly
■ Reset (control dial G)
■ Switch ON
■ Fit new fuse, check connection
if necessary
■ Readjust
■ Firmly press terminal together
Sensor-switched light will
not switch OFF
■ Continued movement within the
detection zone
■ Sensor unit is not properly
engaged
■ Sensor light is in the calbration
phase (user-friendly economy
programme)
■ Check detection zone and readjust
if necessary
■ Lightly press sensor unit to clip it
into place
■ See note on user-friendly economy
programme
LEDs do not go out at
about midnight as desired
■ External light source (e.g. other
motion detector or light) is deacti-
vating the sensor-switched light
■ Shade the sensor-switched light
from extraneous light, then moni-
tor the sensor-switched light for
several days. It takes some time to
return to the correct value
LEDs do not switch OFF
completely
■ Comfort programme selected ■ Turn programme selector dial to 4
Sensor-switched light
switches ON when it
should not
■ Wind is moving trees and bushes
in the detection zone
■ Cars in the street are being
detected
■ Sudden temperature changes
due to weather (wind, rain, snow)
or air expelled from fans, open
windows
■ Use shrouds to precisely define
the detection zone
■ Use shrouds to precisely define
the detection zone
■ Change the detection zone,
change the mounting location
Change in sensor-switched
light reach
■ Diering ambient temperatures ■ Use shrouds to precisely define
the detection zone
